CPU | Intel® Socket 1151 for 7th / 6th Generation Core™ i7/Core™ i5/Core™ i3/Pentium®/Celeron® Processors |
---|---|
Supports 14nm CPU | |
Supports Intel® Turbo Boost Technology 2.0* | |
*Intel® Turbo Boost Technology 2.0 support depends on the CPU type | |
Chipset | Intel® Z270 Chipset |
Memory | 4 x DIMM, max. 64GB DDR4 4000+(OC)*/ 3866(OC)*/ 3733(OC)*/ 3600(OC)*/ 3466(OC)*/ 3400(OC)*/ 3333(OC)*/ 3300(OC)*/ 3200(OC)*/ 3000(OC)*/ 2800(OC)*/ 2666(OC)*/ 2400(OC)*/ 2133 MHz, , non-ECC, un-buffered memory |
Dual channel memory architecture | |
Supports Intel® Extreme Memory Profile (XMP) | |
* Hyper DIMM support is subject to the physical characteristics of individual CPUs. Please refer to Memory QVL(Qualified Vendors List) for details. | |
Expansion Slots | New 7th Gen Intel® Core™ Processors |
2 x PCIe 3.0 x16 slots (supports x16, x8/x8) | |
Intel® Z270 Chipset | |
1 x PCIe 3.0 x16 slot (max. at x4 mode) | |
3 x PCIe 3.0 x1 slots | |
Graphic | Integrated Graphics Processor- Intel® HD Graphics support |
Multi-VGA output support : HDMI/DisplayPort | |
- Supports DisplayPort 1.2 with max. resolution 4096 x 2304 @ 60Hz | |
- Supports HDMI 1.4b with max. resolution 4096 x 2304 @ 24Hz | |
Maximum shared memory of 1024MB | |
Multi-GPU Support | Supports NVIDIA® 2-Way/Quad-GPU SLI™ Technology |
Supports AMD® 3-Way/Quad-GPU CrossFireX™ Technology | |
Storage | Intel® Z270 Chipset with RAID 0, 1, 5, 10, and Intel Rapid Storage Technology 14 support |
- 2 x M.2 Socket 3 with M Key, type 2242/2260/2280(PCIE 3.0 x4 and SATA modes) and type 2242/2260/2280/22110(support PCIE 3.0 x 4 mode) storage devices support * | |
- 6 x SATA 6Gb/s ports ** | |
- Supports Intel® Smart Response Technology *** | |
- Ready for Intel® Optane Memory**** | |
* When the M.2_1 Socket 3 is operating in SATA mode, SATA port 1 will be disabled. | |
* When the M.2_2 Socket 3 is operating in PCIEX4 mode, SATA port 5. 6 will be disabled. | |
** These SATA ports are for data hard drives only. ATAPI devices are not supported. | |
***This function will work depending on the CPU installed. | |
****Intel® Optane Technology only supported when using 7th Generation Intel® Processors. Before using Intel® Optane memory modules, ensure that you have updated your motherboard drivers and BIOS to the latest version from ASUS support website. | |
LAN | Intel® I219-V Gigabit LAN- Dual interconnect between the integrated Media Access Controller (MAC) and physical layer (PHY) |
Anti-surge LANGuard | |
ROG GameFirst IV | |
Audio | ROG SupremeFX S1220 8-Channel high-definition CODEC |
- Supports up to 32-Bit/192kHz playback* | |
- Impedance sense for front and rear headphone outputs | |
- ES9023P High Definition DAC | |
- SupremeFX Shielding Technology | |
- Jack-detection, Multi-streaming, and Front Panel Jack-retasking | |
- Optical S/PDIF out port at back panel | |
Audio Features: | |
- Sonic Studio III | |
- Sonic Radar III | |
*Due to limitations in HDA bandwidth, 32-Bit/192kHz is not supported for 8-Channel audio | |
USB | Intel® Z270 Chipset |
- 6 x USB 3.0 ports ( 4 ports at back panel[blue], 2 ports at mid-board [grey]) | |
- 6 x USB 2.0 ports (4 ports at back panel, 2 ports at mid-board [black])* | |
ASMedia® USB 3.1 controller | |
- 1 x USB 3.1 front panel connector | |
- 2 x USB 3.1 ports (1 Type-A [red] and 1 Type-C [black] at back panel, 1 at mid-board) | |
*2 x USB2.0 port at mid-board share with ROG extension (ROG_EXT) port. | |
Back I/O | 1 x Clear CMOS Button |
1 x BIOS Flashback Button | |
1 x M.2 Wifi Slot | |
1 x HDMI 1.4b | |
1 x DisplayPort 1.2 | |
4 x USB 2.0 ports [black] | |
4 x USB 3.0 ports [blue] | |
1 x Anti-surge LAN (RJ45) port | |
2 x USB 3.1 ports (1 x Type-A [red] and 1 x Type-C [black]) | |
1 x Optical S/PDIF out | |
5 x Gold-plated audio jacks | |
Internal I/O Ports | 2 x AURA RGB headers |
1 x USB 3.1 header | |
1 x USB 3.0 header supports additional 2 USB 3.0 ports | |
1 x USB 2.0 header supports additional 2 USB 2.0 ports [ via ROG_EXT header] | |
6x SATA 6Gb/s ports | |
2 x M.2 Socket 3 for M Key, type 2242/2260/2280 storage devices support (Supports PCIE 3.0 x4 and SATA modes), type 2242/2260/2280/22110 storage devices support (Supports PCIE 3.0 x4 mode) | |
1 x ROG extension (ROG_EXT) header | |
1 x 4-Pin CPU fan connector | |
1 x 4-Pin CPU_OPT fan connector | |
3 x 4-Pin Chassis fan connectors | |
1 x EXT_Fan header | |
1 x 4-Pin W_PUMP+ connector | |
1 x W_IN header | |
1 x W_OUT header | |
1 x W_FLOW header | |
1 x 4-Pin AIO_PUMP connector | |
1 x H_AMP fan connector | |
1 x Thermal sensor connector | |
1 x 24-pin EATX power connector | |
1 x 8-pin EATX 12V power connector | |
1 x Start button | |
1 x Reset button | |
1 x Safe Boot button | |
1 x Retry button | |
1 x LN2 mode jumper | |
1 x Slow mode switch | |
1 x MemOK! Button | |
1 x Clear CMOS Button | |
1 x Thunderbolt header (5-pin) for ASUS ThunderboltEX III series support | |
1 x Front panel audio connector (AAFP) | |
1 x TPM connector | |
1 x System panel connector | |
Accessories | User guide |
Support DVD | |
I/O Shield | |
2 x 2-in-1 SATA 6Gb/s cables | |
1 x SLI™ HB Bridge(2-way-M) | |
1 x Q-Connector | |
1 x ROG Coaster | |
1 x 3D printing mount | |
1 x 10-in-1 ROG cable label | |
1 x CPU Installation Tool | |
1 x 2-in-1 M.2 Screw set | |
1 x ROG sticker | |
Operating System Support | Windows® 10 64-bit |
Windows® 8.1 64-bit* | |
Windows® 7* | |
*Windows® 8.1 64-bit and Windows® 7 32/64-bit are only supported when using 6th Generation Intel® Processors | |
Form Factor | ATX Form Factor, 12”x 9.6” (30.5cm x 24.4cm) |
