CPU | Intel® Socket 1151 for 7th / 6th Generation Core™ i7/Core™ i5/Core™ i3/Pentium®/Celeron® Processors |
---|---|
Supports 14nm CPU | |
Supports Intel® Turbo Boost Technology 2.0* | |
* The support of these features depends on the CPU types. | |
Chipset | Intel® Z270 Chipset |
Memory | 4 x DIMM, max. 64GB DDR4 4000(O.C.)/ 3866(O.C.)/ 3733(O.C.)/ 3600(O.C.)/ 3466(O.C.)/ 3400(O.C.)/ 3333(O.C.)/ 3300(O.C.)/ 3200(O.C.)/ 3000(O.C.)/ 2800(O.C.)/ 2666(O.C.)/ 2400(O.C.)/ 2133 MHz Non-ECC, Un-buffered Memory |
Dual channel memory architecture | |
Supports Intel® Extreme Memory Profile (XMP)* | |
* Hyper DIMM support is subject to the physical characteristics of individual CPUs. Please refer to Memory QVL(Qualified Vendors List) for details. | |
Expansion Slots | 2 x PCIe 3.0/2.0 x16 slots (supports x16, x8/x8) |
2 x PCIe 3.0/2.0 x1 slot | |
VGA | Integrated Graphics Processor- Intel® HD Graphics support |
Multi-VGA output support: DisplayPort/HDMI ports | |
Supports DisplayPort 1.2* with max. resolution 4096 x 2304@24Hz / 3840 x 2304@60Hz | |
Supports HDMI 1.4b with max. resolution 4096 x 2160@24Hz / 2560 x 1600@60Hz | |
Supports Intel® InTru™ 3D/Quick Sync Video/Clear Video HD Technology/Insider™ | |
Supports up to 3 displays simultaneously | |
Maximum shared memory of 1024MB | |
* DP 1.2 Multi-Stream Transport compliant, supports DP 1.2 monitor daisy chain up to 3 displays | |
Multi-GPU Support | Supports NVIDIA® 2-Way SLI™ Technology |
Supports AMD® 2-Way CrossFireX™ Technology | |
Storage | Intel® Z270 Chipset |
- 6 x SATA 6Gb/s ports | |
- 1 x M.2_1 Socket 3 with M key, type 2242/2260/2280 storage devices support (both SATA & PCIE 3.0 x 4 mode) | |
- 1 x M.2_2 Socket 3 with M key, type 2242/2260/2280/21100 storage devices support (PCIE 3.0 x 4 mode) | |
- Intel Optane Memory Ready* | |
* Intel® Optane Technology only supported when using 7th Generation Intel® Processors. Before using Intel® Optane memory modules, ensure that you have updated your motherboard drivers and BIOS to the latest version from ASUS support website. | |
LAN | Intel® I219-V Gigabit LAN- Dual interconnect between the integrated Media Access Controller (MAC) and physical layer (PHY) |
Anti-surge LANGuard | |
ROG GameFirst Technology | |
Wireless&Bluetooth | Wi-Fi 802.11 a/b/g/n/ac supports dual frequency band 2.4/5 GHz with MU-MIMO support |
Bluetooth v4.1, 4.0LE, 3.0+HS | |
Audio | ROG SupremeFX S1220A 8-Channel High Definition Audio CODEC |
- Supports up to 32-Bit/192kHz playback* | |
- Impedance sense for front and rear headphone outputs | |
- High quality 120dB SNR stereo playback output and 110dB SNR recording input | |
- SupremeFX Shielding Technology | |
- Dual Headphone Amplifiers | |
- Jack-detection, Multi-streaming, and Front Panel Jack-retasking | |
- Optical S/PDIF out port at back panel | |
Audio Features: | |
- Sonic Radar III | |
- Sonic Studio III | |
*Due to limitations in HDA bandwidth, 32-Bit/192kHz is not supported for 8-Channel audio | |
USB | Intel® Z270 Chipset |
- 6 x USB 3.0 ports (4 ports at back panel [blue], 2 ports at mid-board) | |
- 6 x USB 2.0 ports (2 ports at back panel [black], 4 ports at mid-board) | |
ASMedia® USB 3.1 controller | |
- 1 x USB 3.1 front panel connector | |
ASMedia® USB 3.1 controller | |
- 2 x USB 3.1 ports (1 x Type-A [red] and 1 x Type-C [black] ports at back panel) | |
Back I/O Ports | 1 x ASUS Wi-Fi GO! module (Wi-Fi 802.11 a/b/g/n/ac and Bluetooth v4.1) |
2 x USB 3.1 ports (1 x typeA [red] and 1 x TypeC [black]) | |
1 x HDMI port | |
1 x DP port | |
2 x USB 2.0 ports [black] | |
1 x PS/2 keyboard/mouse combo port | |
4 x USB 3.0 ports [blue] | |
1 x Anti-surge LAN (RJ45) port | |
5 x Audio jacks | |
1 x Optical S/PDIF out | |
Internal I/O Ports | 1 x USB 3.1 front panel connector |
1 x USB 3.0 connector supports additional 2 x USB 3.0 ports | |
2 x USB 2.0 connectors support additional 4 x USB 2.0 ports | |
6 x SATA 6Gb/s connectors | |
1 x 4-Pin CPU_FAN connector | |
1 x 4-Pin CPU_OPT fan connector | |
1 x 4-Pin W_PUMP+ connector | |
2 x 4-Pin CHA_FAN connectors | |
1 x 24-pin EATX power connector | |
1 x 8-pin EATX 12V power connector | |
1 x M.2_1 Socket 3 for M Key, type 2242/2260/2280 storage devices support (both SATA & PCIE 3.0 x 4 mode) | |
1 x M.2_2 Socket 3 for M Key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode) | |
1 x Front panel audio connector (AAFP) | |
1 x TPM connector | |
2 x RGB Header | |
1 x Clear CMOS jumper | |
1 x Thermal sensor connector | |
1 x System panel connector | |
1 x CPU_OV jumper | |
Accessories | User guide |
ROG motherboard support DVD | |
1 x I/O Shield | |
2 x 2-in-1 SATA 6Gb/s cables | |
1 x SLI HB BRIDGE (2-WAY-S) | |
1 x ASUS 2T2R dual band Wi-Fi moving antennas (Wi-Fi 802.11a/b/g/n/ac compliant) | |
1 x RGB LED extension cable | |
1 x CPU Installation tool | |
1 x ROG cable label set | |
1 x ROG Strix sticker | |
1 x 3D Printing Mount | |
2 x M.2 screws kit | |
1 x ROG Coaster | |
Operating System Support | Windows® 10 64-bit |
Windows® 8.1 64-bit* | |
Windows® 7* | |
*Windows® 8.1 64-bit and Windows® 7 32/64-bit are only supported when using 6th Generation Intel® Processors. | |
Form Factor | mATX Form Factor, 9.6”x 9.6” (24.4cm x 24.4cm) |
